0
06430-HC4-901
SHOE SET,BRAKE
450:-
1
43120-943-680
SHOE, RR. BRAKE, åtgår 2st
*
2
35350-KJ9-405
SWITCH ASSY.,RR.S
215:-
2
35350-336-000
(35350-KJ9-405) SWITCH,STOP LAMP
215:-
3
35357-046-000
SPRING, SWITCH
30:-
5
40543-312-010
ADJUSTER,CHAIN
240:-
5
40543-471-000
ADJ.,DRIVE CHAIN
240:-
7
42313-369-000
COLLAR,RR BRAKE
*
8
43100-369-010
PANEL,RR.BRAKE
*
9
43141-369-000
CAM, REAR BRAKE
*
10
43145-369-000
PLATE,INDICATOR
*
11
43411-362-000
ARM,REAR BRAKE
*
12
43434-286-000
RUBBER CUSHION
35:-
13
43451-377-000
ROD COMP,RE BRAKE
*
14
45133-329-000
SPRING,FR.BRAKE, åtgår 2st
45:-
15
45134-250-000
DUST-SEAL, BRAKE
25:-
16
46500-377-000
PEDAL COMP,BRAKE
*
18
46514-377-000
SPR,BRAKE PEDAL
*
19
46515-377-000
SHAFT COMP,PIVOT
*
20
52136-333-000
STOPPER,CHAIN ADJ
169:-
21
90119-283000
BOLT, CHAIN
185:-
22
90127-283000
BOLT, PANEL STOP.
103:-
23
90307-283000
NUT, CHAIN
40:-
24
90524-030000
WASHER, HANDLE, åtgår 2st
30:-
25
90549-121000
WASHER,PLAIN 14MM
20:-
26
92000-06022
BOLT,HEX.6X22
20:-
26
92000-0602200
BOLT HEX 6X22
20:-
26
92101-060220A
BOLT,HEX.,6X22
25:-
27
92000-080280A
BOLT,HEX 8X28
35:-
27
92101-080280A
BOLT HEX 8X28
35:-
28
94001-080000S
NUT,HEX.,8MM
10:-
29
94201-16120
PIN,SPLIT, 1.6
10:-
30
94201-20350
PIN COTTER 2.0MM
10:-
31
94251-08000
PIN,LOCK,8MM
15:-
32
95014-73100
SPG.A,BRAKE ROD
20:-
32
95014-73300
SPRING,BRAKE ROD
20:-
33
95015-32001
JOINT, BRAKE ARM
20:-
34
95015-42000
NUT,ADJUST
50:-
35
95015-52000
PIN,JOINT
50:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
