1
11342-300-060
COVER,CLUTCH
*
2
11348-392-000
COVER,CLUTCH
*
3
11396-300-060
GASKET,CLCH.COVER
*
4
22810-300-000
LEVER,CLUTCH
133:-
5
22815-300-000
SPRING,CLUTCH
50:-
6
22820-300-000
SHAFT,RELIESE
*
6
22820-410-010
SHAFT,CLCH.RELESE
*
7
22830-300-000
CAMLIFTER,CLUTCH
227:-
7
22830-410-010
CAM,CLUTCH LIFTER
*
8
22841-300-000
BOLT,ADTUST
131:-
8
22841-410-000
ROD,CLUTCH ADJUST
*
9
22860-300-006
RETAINER,BALL
*
10
90402-822000
WASHER,HEAD,8MM
*
11
91202-216003
OIL SEAL, 14X24X5
65:-
12
91204-286003
OIL SEAL,18X29X7
40:-
12
91204-286005
OIL-SEAL,18X29X7
40:-
13
91301-283005
O-RING,5X2.4
45:-
14
93500-06028
SCREW CROSS 6X28, åtgår 7st
15:-
16
93700-0601602
SCREW,CROSS 6X16, åtgår 3st
15:-
17
94002-080000S
NUT,HEX.,8MM
10:-
18
94301-08140
DOWEL,PIN,8X14, åtgår 2st
25:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
