1
13495-300-000
RING A SET, åtgår 2st
*
2
23150-300-010
HOLDER,SHAFT
696:-
3
23210-392-000
MAINSHAFT,TRNS.
*
4
23220-371-000
COUNTERSHAFT,
*
5
23421-300-050
GEAR,LOW
*
6
23425-392-000
BUSH,SPLINE 29MM
*
7
23431-392-000
GEAR,M.2.3
*
8
23440-392-000
GEAR,CT/SHAFT 2ND
*
9
23440-410-305
GEAR,CT/SHAFT 2ND
*
10
23441-410-000
(23441-431-000) GEAR,CT/SHAFT 2ND
*
11
23450-392-000
GEAR,M/SHAFT 4TH
*
12
23460-392-000
GEAR,CT/SHAFT 3RD
*
13
23460-410-305
GEAR,CT/SHAFT 3RD
2650:-
14
23461-410-000
GEAR,CT/SHAFT 3RD
*
15
23471-300-010
GEAR,FOURTH
1794:-
16
23481-300-020
GEAR,MAIN TOP
*
17
23485-392-000
BUSH,SPLINE 28MM
443:-
18
23485-410-010
BUSH,28MM, åtgår 2st
*
18
23485-410-003
BUSH,28MM
*
20
23501-392-000
GEAR,FINAL DRIVE
*
21
90451-371000
WASHER,THRUST, åtgår 3st
*
21
90451-371000
WASHER,THRUST
*
22
90452-371000
WASHER, 25X34, åtgår 2st
70:-
23
90458-292000
WASHER,THRUST
95:-
24
90458-506810
THRUST WASHER A
*
25
90601-300000
CIRCLIP,25M/M, åtgår 5st
55:-
26
90809-300300
PLUG,SPECIAL10X10
*
29
91003-235000
B/BRG RAD N/COM
425:-
30
91301-283005
O-RING,5X2.4
45:-
31
93600-06020
SCREW, FLAT, 6X20, åtgår 4st
10:-
32
96100-62040
(96100-620-4000) B/BRG RAD N/COM
200:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
