1
13610-393-004
CHAIN,PRIMARY.
*
2
15211-425-000
GEAR,OIL PUMP
*
3
15710-438-000
NOZ,CHAIN FEED
*
4
23103-425-300
GEAR,PRIM DRIVE
*
5
23105-425-003
COLLAR,P.GEAR
*
6
23110-425-000
(23110-425-010) SHAFT,PRIMARY
*
7
23112-425-300
SPROCKET,PRIMARY
*
8
23114-425-300
HUB,DRIVEN SPRKT
*
9
23115-425-300
RUBBER,DAMPER, åtgår 8st
100:-
10
23123-425-300
PLATE,SIDE
*
11
23124-425-300
GEAR,PRIM.DRIVE
*
12
23125-425-005
SPRING,DISK
55:-
13
23132-425-000
GUIDE,PRIM.CHAIN
*
14
23160-425-000
BASE,PRIM CHAIN
*
15
23167-422-010
BAR ASSY.,PUSH
*
16
23168-425-000
SPG,PRIM.TENSION.
*
17
23175-425-000
PIPE,PRIM CHAIN
*
18
23180-425-000
BODY,TENSION VLV
*
19
23182-425-000
WASHER,STOPPER
*
21
27611-393-000
VLV,T.C FLUID
*
22
27621-393-000
SPG,T.C FLUID
*
23
30905-216-000
PIN, KNOCK, 3X5.2
35:-
24
90013-425003
BOLT,PRIM.SHAFT
*
25
90416-500000
PIPE WASHER
*
26
90453-426000
WASH,THRUST22.5MM
*
27
90475-425000
WASHER,THRUST 30
45:-
28
90483-700000
WASHER,14MM, åtgår 2st
*
29
94101-06000
WASHER,PLAIN, 6MM
10:-
30
90601-393000
RING,SET,56MM
*
31
90731-425000
PIN,LOCK,10MM
*
32
91007-393003
B/BRG RAD N/COM
*
33
91257-425013
OIL SEAL,25X47X10
180:-
34
91302-377000
O-RING,15X2.5, åtgår 2st
80:-
35
92000-06014
BOLT,HEX 6X14, åtgår 3st
20:-
36
94050-06000
NUT,FLANGE,6MM
15:-
37
94201-16220
PIN COTTER 1.6MM
15:-
38
94510-17000
CIRCLIP,17MM
15:-
39
94510-20000
CIR CLIP,EX.20
15:-
40
94510-30000
CIRCLIP, 30M/M
40:-
41
95700-0601200
BOLT, FLANGE,6X12, åtgår 2st
20:-
42
96100-62040
(96100-620-4000) B/BRG RAD N/COM
200:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
