1
12110-12003
PISTON STD
*
1
12100-12000-050
PISTON/RING KIT
*
1
12110-12003-100
PISTON O.S1.0
*
2
12140-12012
PISTON RING SET
*
2
12140-28630-050
RING SET, PISTON (OS:0.5)
1400:-
4
09381-14001
CIRCLIP, åtgår 2st
25:-
5
09263-14022
ROLLER BEARING
245:-
6
12200-12003
CRANKSHAFT ASSY
*
7
12161-39300
CONNECTING ROD
1145:-
8
09160-19001
THRUST WASHER, åtgår 2st
50:-
9
12211-03300
PIN, CRANK
570:-
10
09263-19009
BEARING (P; O.D.=25(0.98),I.D.=20(0.79)27))
345:-
11
12221-12004
CRANKSHAFT,RH
*
12
12261-12004
CRANKSHAFT,L
*
13
09181-20158
WASHER
40:-
15
09283-20034
OIL SEAL, RH (00; ID=25(0.98) OD=377(0.28))
85:-
16
09262-20073
BEARING, DRIVE SHAFT, RH
480:-
18
09262-20015
BEARING, RH (00 ID=20(0.79) OD=52(2.0.59))
880:-
21
12421-05210
GUIDE, VALVE
410:-
22
04221-03059
PIN
25:-
23
12450-12001
SEAT,CRKC OUTER
*
25
09280-10012
O RING (D:1.5,ID:10)
35:-
26
09280-99001
O RING, OUTER VALVE SEAT
70:-
29
02122-06167
SCREW, åtgår 6st
25:-
30
02122-0620A
SCREW, åtgår 5st
30:-
34
09140-14002
PRIMARY DRIVE GEAR NUT (M12MARK2,M15D,M12 UP TO106050)
45:-
35
09166-14009
WASHER, PRIMARY DRIVE GEAR
*
36
09420-04008
KEY
55:-
37
08341-31039
KEY
30:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
