1
13401-41D31
ELEMENT ASSY, THERMO
*
1
13401-25E01
ELEMENT ASSY, THERMO
4700:-
2
13278-39C60
O RING
120:-
4
13601-04228
SCREW
70:-
5
13511-29C50
JOINT
95:-
6
13394-40D00
CLIP, NEEDLE
50:-
7
13383-09E10
JET NEEDLE (3L38)
*
7
13383-09E00
JET NEEDLE (3L36)
265:-
7
13383-29C50
NEEDLE, JET (3L30-4)
*
8
13551-09E00
VALVE, PISTON
*
9
09494-00823
NEEDLE JET (E-3)
*
9
09494-00865
NEEDLE JET (E-0)
*
10
09491-55006
JET, MAIN (55)
235:-
11
09492-20023
JET, PILOT (20)
240:-
11
09492-17014
JET, PILOT (17.5)
*
12
13370-25E00
VALVE ASSY, NEEDLE
1420:-
13
13250-29C50
FLOAT
610:-
14
13254-29C50
PIN, FLOAT
75:-
15
13258-29C50
GASKET
140:-
16
02112-35163
SCREW, åtgår 2st
25:-
17
13247-25E00
SCREW, DRAIN
445:-
18
13278-02340
O RING
35:-
20
13373-46710
PLATE
85:-
22
13543-09400
SPRING
80:-
23
13540-25E00
LEVER SET, THROTTLE
515:-
23
02112-34123
SCREW
25:-
24
13550-29C50
SHAFT ASSY, THROTTLE
800:-
25
13557-09400
PLATE
140:-
26
13574-29C50
RING
80:-
28
13573-25E10
SPRING
240:-
29
13569-29C50
GUIDE, CABLE
150:-
30
13484-29C50
COVER, THROTTLE
*
31
13237-29C50
GASKET
155:-
32
02112-74103
SCREW, åtgår 2st
25:-
33
13268-35010
.SPRING (K,L,M,A,BR)
50:-
34
13291-35010
WASHER
40:-
35
13295-33010
O RING (K,LM,A,B)
50:-
36
13267-25E00
ADJUSTER
240:-
37
13278-29C50
O RING
90:-
38
09493-22005
JET, PILOT AIR (1.1)
220:-
38
09493-24007
JET, AIR (1.2)
220:-
40
09352-30503-300
HOSE (3X5X300)
*
41
09404-06429
CLAMP
20:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
