1
24121-27A01
COUNTERSHAFT (NT:13)
*
2
24221-27A01
GEAR, 2ND DRIVE (NT:16)
1505:-
3
09380-25006
CIRCLIP
25:-
4
24231-27A00
GEAR, 3/4TH DRIVE (NT:17/20)
2120:-
5
24251-27A01
GEAR, 5TH DRIVE (NT:22)
*
7
09380-25003
CIRCLIP, åtgår 2st
50:-
9
09167-25012
WASHER
50:-
10
09262-25051
BEARING, RH
1160:-
12
09285-20006
SEAL, OIL
105:-
13
24741-27A00
RETAINER, CNTR SHAFT
130:-
14
02122-06167
SCREW, åtgår 2st
25:-
15
09263-20049
BEARING, CNTR SHAFT, LH
1110:-
16
04221-07129
PIN
30:-
17
24131-27A02
DRIVESHAFT
*
18
24311-27A01
GEAR, 1ST DRIVEN (NT:36)
*
19
09300-22008
BUSH (22X27X0.5)
195:-
20
08211-20341
WASHER, RH
40:-
21
08211-22341
WASHER, LH
50:-
23
09300-28001
BUSH
*
26
24331-27A00
GEAR, 3RD DRIVEN (NT:28)
1960:-
27
24332-27A00
BUSH, 3DR DRIVEN GEAR
200:-
28
09167-28001
WASHER (28.1X38X1.0)
60:-
29
09167-28002
LOCK WASHER, LH
60:-
30
09169-28001
LOCK WASHER, RH
50:-
32
24332-27A00
BUSH, 3DR DRIVEN GEAR
200:-
33
09167-28001
WASHER (28.1X38X1.0)
60:-
34
24351-27A00
GEAR, 5TH DRIVEN (NT:27)
1795:-
36
09263-20040
BEARING, DRIVE SHAFT RH
955:-
37
04221-07209
PIN, DRIVE SHAFT BRG RH
30:-
40
09283-34005
SEAL, DRIVE SHAFT OIL
205:-
43
27511-27A11
SPROCKET, ENGINE (NT:14)
510:-
45
27517-31300
DAMPER, ENGINE SPROCKET, åtgår 2st
240:-
46
09180-25080
SPACER
*
47
09159-20004
NUT, ENGINE SPROCKET
245:-
48
09280-25001
O RING (D:1.0,ID:24.5)
25:-
51
08212-06222
WASHER
25:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
