1
18700-17C02
CLEANER ASSY, 2ND AIR
*
3
18750-17D00
BRACKET,AIR CLEANER,RH
*
4
18760-17D00
BRACKET,AIR CLEANER,LH
*
6
18523-40C01
SPACER, BRACKET, LOWER
*
7
18524-40C01
SPACER, BRACKET, UPPER
*
8
18550-40C01
HOSE, 2ND AIR, NO.3
*
9
09401-25402
CLIP
*
10
18510-48B00
VALVE ASSY, AIR SWITCING
*
11
18522-17C00
CLAMP, SWITCHING VALVE
170:-
12
09399-45852-550
HOSE,VACUUM
*
13
09401-07401
CLIP
*
14
18481-40C00
HOSE, 2ND AIR NO.2,RH
*
15
18482-40C00
HOSE, 2ND AIR NO.2,LH
*
16
09401-21401
CLIP, åtgår 4st
*
17
18450-48B00
VALVE ASSY, 2ND AIR REED, åtgår 2st
*
18
07110-05167
BOLT, åtgår 4st
*
19
18520-17D00
BRACKET,AIR VALVE
*
21
18445-17D00
HOSE, 2ND AIR NO.1, RH IN
*
22
18447-17D00
HOSE, 2ND AIR NO.1, RH OUT
*
23
18446-17D00
HOSE, 2ND AIR NO.1, LH
*
24
18448-17D00
HOSE, 2ND AIR NO.1, LH OUT
*
25
09401-13408
CLIP, åtgår 8st
*
26
18401-17D01
PIPE,2ND AIR,RH
*
27
18402-17D01
PIPE,2ND AIR,LH
*
28
18428-48B00
CUSHION, åtgår 2st
*
30
18441-17C00
GASKET,AIR PIPE, åtgår 4st
*
31
01421-06125
STUD BOLT, åtgår 8st
*
34
18731-17C00
HOSE, CLEANER INLET
*
35
18519-17C00
CUSHION, SWITCING VALVE, åtgår 2st
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
