1
13251-04110
GASKET, FLOAT CHAMBER
60:-
2
09492-15002
JET, PILOT (15)
*
3
09492-15009
JET, PILOT NO.2
135:-
4
09491-52002
JET, MAIN (52.5)
140:-
5
09494-00210
JET, NEEDLE (E-4)
*
6
13383-19010
NEEDLE, JET (3E3-3)
165:-
9
13267-01010
SCREW, THROTTLE STOP
65:-
10
13268-01010
SPRING (M12MARK2,M15D,M12M12MARK2,M15D,M12)
50:-
11
13581-04010
SEAT, THROTTLE VALVE SP
70:-
13
13573-01010
SPRING, THROTTLE VALVE
50:-
15
13682-98010
CAP, STARTER
40:-
16
13551-04110
VALVE, THROTTLE (CA:3.0)
265:-
17
13663-31010
GASKET, VALVE SEAT
30:-
18
13370-04110
VALVE, NEEDLE
260:-
21
13417-18630
SPRING
55:-
22
13411-04410
VALVE, STARTER
140:-
23
13269-04010
SCREW, PILOT AIR
120:-
24
13268-01010
SPRING (M12MARK2,M15D,M12M12MARK2,M15D,M12)
50:-
27
13247-05010
PLUG, DRAIN
55:-
28
13249-05010
GASKET, DRAIN PLUG
20:-
29
13435-33110
BALL
20:-
30
13434-30650
SPRING
40:-
31
13413-04410
LEVER, STARTER
*
32
13424-30650
RING
60:-
33
13252-04011
FLOAT
255:-
34
13254-04010
PIN, FLOAT
40:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
