1
27311-38A00
GEAR, FINAL DRIVE BEVEL
3885:-
1
27320-45C01
GEAR, FINAL DRIVEN BEVEL
5640:-
2
27312-38A00
STOPPER, BEARING
950:-
3
27313-45C00
PLATE
*
4
27313-38A60
PLATE
*
5
09280-62002
O RING (D:1.9,ID:61.6)
50:-
6
09267-30005
BEARING (30X62X23.8)
2000:-
7
09263-17028
BEARING (17X32X16)
790:-
8
09160-16029
WASHER, DRIVE SHAFT
85:-
9
09159-16010
NUT
150:-
10
09283-38009
SEAL, FINAL DRIVEN GEAR OIL L
235:-
11
27445-38810
SHIM SET, FINAL (T:0.3/0.35/0.4/0.5/0.6)
315:-
12
09108-10095
STUD BOLT, åtgår 3st
75:-
13
09164-10008
WASHER, åtgår 3st
30:-
14
09159-10026
NUT, åtgår 3st
100:-
15
09262-70001
BEARING, FINAL DRIVEN RH
2355:-
16
27327-34810
SHIM SET, DRIVE GEAR BEARING (T:0.35/0.4/0.5/0.6)
490:-
17
27328-34200
PLATE
95:-
18
09289-70001
SEAL, FINAL DRIVEN GEAR OIL R
825:-
19
09263-32007
BEARING, LH (32X46X17.7)
1310:-
20
27326-34820
SHIM SET, FINAL DRIVE GEAR (T:1.05/1.1/1.2/1.25/1.35)
270:-
20
27326-34810
SHIM SET, FINAL DRIVE GEAR
170:-
21
27329-34200
RETAINER, BEARING
110:-
23
09283-30028
OIL SEAL (30X42X7)
150:-
24
27450-45C01-13L
CASE,FINAL GEAR
10545:-
24
27450-45C01-23W
CASE,FINAL GEAR
*
24
27450-45C01-13L
CASE,FINAL GEAR
10545:-
25
27481-45C00
STUD BOLT
*
26
27460-07A01
CASE, FINAL GEAR BEARING
2395:-
27
09280-00015
O RING (D:3.5,ID:131.6)
150:-
29
09247-18007
PLUG, OIL FILLER
*
30
09280-18004
O RING (D:2.4,ID:17.8)
85:-
32
09168-14004
GASKET (14.1X18X1.5) (M12MARK2,M15D,M12 2 PCSO.M10-152331)
25:-
32
09168-14002
GASKET (13.8X18.8X0.4)
45:-
33
27172-38A00
COUPLING, PROPELLER SHAFT
860:-
34
27100-38A50
YOKE, UNIVERSAL JOINT
*
35
27151-45C01
SHAFT,PROPELLER
*
36
09440-18019
SPRING
45:-
37
09283-30051
OIL SEAL (28.4X48X15)
170:-
38
09381-40003
CIRCLIP
75:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
