1
T1190909
Selector Drum Assembly
6010:-
3
T3800090
Bearing Ball, Unshld, 20x42x8
125:-
4
T1190926
Plate retaining
70:-
5
T1190915
Detent wheel
675:-
6
T3331041
Screw, Pan/Hd, Tx, M6 x 25, Enc
20:-
7
T1190165
Detent arm assembly
> Eng No 330785
390:-
7
T1190169
Detent Arm Assy
Eng No 330786 >
350:-
8
T3555017
Washer, 6.5 x 12.5 x 0.8
50:-
9
T3051058
Screw, Cap/HD, M6 x 20, Enc
20:-
10
T1190192
Collar, Detent Arm
35:-
11
T1190923
Spring, Detent Arm
70:-
12
T1191002
Fork, C, Selector, Output
1580:-
13
T1191001
Selector fork
1580:-
14
T1191000
Fork, A, Selector, Output
1580:-
15
T1190610
Selector shaft
» ENG NO 146927
690:-
15
T1190069
Shaft, Selector, Gearbox
ENG NO 146928 »
640:-
16
1190110-T0301
Plate keeper
» ENG NO 146927
45:-
16
T1190101
Keeper Plate, Selector Shaft
ENG NO 146928 »
85:-
17
T3331042
Screw, Pan/Hd, Tx, M6 x 12, Enc
25:-
18
T1190282
Neutral Switch
655:-
19
T3550546
Washer, Cu, OD 16 x ID 10.2/
20:-
20
T1190850
Gearchange Shaft Assy
2605:-
22
T3500044
E Circlip, åtgår 3st
20:-
23
T1191143
Pin, Spring Abutment
170:-
24
T3555003
Washer, 12 x 18 x 1.2, åtgår 2st
25:-
25
T2081009
Pedal assembly
2095:-
26
T2080766
Rubber, Gearchange Pedal
160:-
29
T3750006
Bush
190:-
30
T2081078
Rod, Gearchange
455:-
31
T3350300
Nut, M6 x 1.0, Slv
20:-
32
T3350304
Nut, M6, LH Thread
LH thread
30:-
36
T3050334
Screw, Cap/Hd, M6 x 20, Slv
M6 x 20mm
25:-
