1
T2010074
Rear Wheel Assy, 5.5 X 17
> 333178
21425:-
1
T2010561
Rear Wheel Assy, 5.5 x 17
333179 >
19830:-
2
T2006615
Valve Assy, aluminium, 90, Slv
265:-
3
T3700207
Clip, Locking
50:-
4
T2012596
Nut, M38, Slv
655:-
5
T3555036
Washer, Conical, 38.5 x 55.5 x 3.5
230:-
6
T3550955
Thrust Washer, Plated
190:-
7
T2012575
Conical Spacer, Anodised
470:-
8
T2012299
Axle, Rear, Assy
10235:-
9
T2012297
Drive Pin, åtgår 4st
580:-
10
T3050211
M6 Bolt, Pan Head, åtgår 4st
50:-
11
T3500050
Circlip, Nom Shaft 75 Dia
35:-
12
T2012432
Eccentric Assy
6380:-
13
T3600145
Seal, Grease, åtgår 2st
> 346969
70:-
14
T3501055
Snap Ring, Nom Bore 55 Dia
30:-
15
T3800220
Bearing, Needle Roller
> 346969
1055:-
15
T3800221
Bearing, Needle,45x55x25, Sealed
346970 >
1620:-
16
T3500209
Circlip, Int. 55 x 2
85:-
17
T3800170
Bearing, Twin Ball
1540:-
18
T3501062
Snap Ring, Bore 62 Dia
50:-
20
T2012386
Cush Drive Assy
11690:-
21
T2010330
Chain, Final Drive, 106L, Did
2370:-
22
T2012400
Cush rubber, åtgår 5st
375:-
23
T3600155
O Ring, Cush
115:-
24
T2012620
Bearing, Spacer
260:-
25
T2012381
Cush, Outer
6850:-
26
T3800150
Bearing, Twin Ball
1040:-
27
T3050265
Bolt, Pan Hd, Shld, M8 x 32, åtgår 6st
95:-
28
T2012495
Sprocket, Rear, 42T
700:-
29
T3350004
Locknut, Flanged, M8, åtgår 6st
45:-
30
T2012614
Flanged Sleeve, 30 x 45 x 7.5
125:-
31
T3555034
Conical Washer, 35.5, 51, 5.3
265:-
32
T2012536
Nut, M35, Slv
510:-
33
T3600145
Seal, Grease
70:-
34
T2012360
Cush Centre
2505:-
35
T2017430
Chain & Sprocket Kit, 106/42/18
3470:-
